Constant changing of automotive air conditioning systems
The technological development of vehicles aims to continuously improve safety, efficiency and environmental impact. The most recent regulatory framework for vehicle cooling and heating systems, EU 517/2014, stipulated the reduction of refrigerants with a high global warming potential (GWP). Since 2017, vehicle air conditioning systems in many countries around the world must use refrigerants with a GWP <150. HFO1234yf gas with a GWP of 4 has become the popular solution with a GWP 350 times lower than its predecessor R134a with a GWP of 1.470.
The environmentally friendly alternative
Some car manufacturers have followed also the environmentally friendly alternative of using carbon dioxide as a refrigerant and are installing these systems in some of their vehicle models. Carbon dioxide (R744) occurs naturally, is biodegradable and offers the best possible ecological result with a GWP of 1 (zero impact on ozone depletion). Increased awareness of environmental protection, cost-effectiveness and the efficiency that can be achieved with the properties of R744 are further encouraging the use of R744 systems as a long-term and future-oriented solution in the premium vehicle sector.
The Sun R744 solution
Sun presents the new ECO2KARE air conditioning service device for the growing workshop needs of specific maintenance and repair on R744 air conditioning systems. The thermodynamics of R744 refrigerant differ fundamentally from the chemical refrigerants with new requirements for the air conditioning system itself and the necessary air conditioning service device. Particularly noteworthy are the very high pressures of up to 130 bar and additional safety precautions to avoid increased CO2 concentrations in the vehicle or in the workshop's working environment. ECO2KARE has been developed for the specific safety and high-pressure requirements of R744 air conditioning systems. The device is distinguished by high-quality and powerful components, future-oriented standard features and extremely intuitive user friendliness via the 7'' touchscreen.
Fully automatic air conditioning service unit for emptying, servicing and filling R744 air conditioning systems
- Simple, fast and highly intuitive navigation on a 7” touchscreen with Linux operating system
Navigation is extremely easy through images, icons, short texts and the virtual keyboard - Absolutely safe: software guided processes include all necessary control instructions and constant monitoring of the CO2 concentration in the atmosphere
- Integrated Hybrid feature for the flushing of service hoses and internal circuits. Indispensable for the safe service on systems with an electric compressor
- Very powerful 142 l / min double-stage vacuum pump keep the station suitable for big systems, too (trains, buses) and guarantees a highly efficient vacuum phase for drying the system, particularly important for CO2 systems
- Heating system with manual setting option for extended heating speeds up filling process and helps to save time
- Management of 3 high-quality, hermetic, refillable containers for compressor oil(1x PAG and 1x POE) and dye (included in the scope of delivery)
- Automatic pressure test with nitrogen or hydrogen/nitrogen mixture
- 3 m service hoses for a smart connection to the vehicle
- Large pressure gauges 100 mm
- Status light
- Easy changing of R744 tanks of different sizes, protection cover and fastening with Swift safety belt
- Possible refrigerant bottles: the gross weight of up to 50 kg allows the use of usual commercial sizes for refrigerant quantities from 1 to 22.6 kg, height from 35 cm to 120 cm including connections and a diameter from 10 cm to 21 cm.
- Connection to the bottle: hose 1 m, RAC8164 adapter W21, 7x1/14‘‘ – ¼ SAE male, RAC8165 adapter W21, 8x1/14‘‘ – ¼ SAE male
- Quick plug-in connection for CO2 discharge hose (PA12 8x10 mm, TUB1259)
- Efficient internal ventilation against icing of internal components
- Online update via USB interface or directly in Wi-Fi connection
- Generous storage compartment for accessories
- Very service-friendly
- Very robust structure for best protection of the station
- Convenient and cost-effective due to low maintenance needs and minimal use of consumables
- Environmentally friendly packaging made of wood and paper without the use of polystyrene
- Simple, fast and highly intuitive navigation on a 7” touchscreen with Linux operating system
TECHNICAL FEATURES
Model Sun ECO2KARE Type of refrigerant R744 Display 7'' colour touchscreen Service valves Automatic Thermal printer Standard Hybrid Standard Pressure test forming gas / nitrogen Standard, max pressure 100 bar Analizer (KIT.GAS) not applicable Connectivity Wi - Fi Standard Flushing Kit not applicable Vacuum leak detection Standard Recharge method CAR CO2 measurement" discharged yes Pressure gauges 100 ø mm Hoses 3 meters Data Base base + custom records Safety Sensor environmental CO2 level yes Oil injection Automatic Dye injection Automatic Hermetic and refillable containers for oil and dye Standard 2 + 1 Hermetic disposable containers for oil and dye Option 2 + 1 Refillable standard containers for oil and dye Not available Refrigerant configuration not applicable Non condensable gas purge not applicable Volt 220 - 240V 50/60 Hz (CE), 110V 60 Hz (ETL) Vacuum pump 142 l/min double stage, 3 Pa / 0,03 mbar Sealed compressor not applicable Recovery speed not applicable (discharge speed is applicable) Tank Scale resolution 10 gr Oil scale resolution 5 gr Working temperature range 10/48°C Filter system not applicable Refrigerant tank no internal tank. Scale max gross weight 50 kg Bottle heater Standard (with setting option for extended heating) Status light Standard Quick couplers SAE J639 Refrigerant scale max load 50 kg / 110 lb Max operating pressure 160 bar Exhausted oil container capacity 500 ml Refrigerant charge automatic Emergency Stop button Standard Casing Metal with robust plastic cover (thermoformed) Dimension / weight cm 67 x 88 x 110, 90 kg Dimension / weight with packaging cm 74 x 112 x 125, 100 kg, no double stacking
