HD-S

The power performer for big a/c systems

HD-S

The power performer for big a/c systems

SUN’ special product for refrigerant R134a. Performance parameters for HD-S comply with the increased capacities required for services on big A/C systems, such as buses and trains.

  • FEATURES:

    • Fully automatic A/C service station for recovery, recycling and recharging with refrigerant R134a on very large A/C systems
    • Special refrigerant high pressure gear pump
    • Capacity of 1 kg/min flow rate in the liquid phase
    • Alphanumerical display
    • The pressure test with forming gas or nitrogen provides an ecological method for leak detection
    • Automatic discharge of “non-condensable” gases from the internal tank
    • The workshop-oriented design is user-friendly and space saving
    • High quality materials
  • TECHNICAL DATA:

    Type of refrigerant: R134a
    Voltage: 220-240v  50/60 Hz
    Vacuum pump: 170 l/min, vacuum level 0,1 mbar
    Sealed compressor: 21 cc
    Recovery speed: 300 g/min in liquid phase
    Scale resolution: 10 gr
    Oil scale resolution: 5 gr
    Working temperature range: 11/49 °C
    Filter system: 2 filters for humidity
    Refrigerant tank: 40 liters refillable
    Hoses: 6 meters
    Display: LCD alphanumeric mm 146 x 82,5
    Pressure test forming gas / nitrogen: Standard
    Thermal printer: Standard
    Refillable standard containers for oil and dye: Standard 1+ 1
    Automatic air purge: Standard
    Dimension / weight: cm 80 x 84 x 115, 127 kg
    Dimension / weight with packaging: cm 91 x 91 x 126, 137 kg
