BREEZE IV

The easy solution for tomorrow’s workshop

BREEZE IV

The easy solution for tomorrow’s workshop

BREEZE IV is the new model designed for different types of refrigerants. Future-oriented and premium quality components make BREEZE IV the most valuable A/C service station.

  • FEATURES:

    • Fully automatic A/C service station for recovery, recycling and recharging of different types of refrigerants
    • The innovative and exclusive solution allows to set the R134a or the HFO1234yf gas directly during activation in the workshop.
    • 4,3” touch screen display
    • With its modular features, the machine can be configured to meet the most specific needs
    • The upgrade with the Gas Analyser detects the different components of the refrigerant, and the result provides information about their percentages
    • Hybrid Kit (optional)
    • WI-FI connectivity (optional)
    • C.A.R. method (Compressor Assisted Recharge)
    • With the advanced technology based on an innovative solenoid valve system, BREEZE IV consumes 20% less energy than the previous models
    • Futuristic design
    • Less than 30” to open the revolving control panel
    • BREEZE IV grants excellent maneuverability as a result of the considerable axial distance between the two wheels
    • User-friendly
  • TECHNICAL DATA:

    Type of refrigerant: HFO1234yf or R134a
    Voltage: 220-240V  50/60 Hz
    Vacuum pump: 51 l/min, vacuum level 0,2 mbar
    Sealed compressor: 1/3 HP
    Recovery speed: 300 g/min  in liquid phase
    Scale resolution: 10 gr
    Working temperature range: 11/49 °C
    Filter system: 1 filter for humidity
    Refrigerant tank: 12 liters refillable
    Hoses: 3 meters
    Display: 4,3’’ color touchscreen
    Connectivity WI-FI: Option
    Hybrid function / electrically driven compressors: Option
    Gas identifier / Gas Analyser: Option, Analyser
    Flushing kit: Option
    Thermal printer: Standard
    A/C diagnosis: Standard (R134a)
    Hermetic disposable containers for oil and dye: Option 1
    Refillable standard containers for oil and dye: Standard 1
    Dimension / weight: cm 67 x 68 x 108, 63 kg
    Dimension / weight with packaging: cm 71 x 74 x 125, 81 kg
