BLIZZARD QTECH IV

A future-oriented user experience

BLIZZARD QTECH IV

A future-oriented user experience

QTECH IV is the new model designed for different types of refrigerants. Future-oriented standard features, WI-FI connectivity and premium quality components make QTECH IV an ambassador among most modern A/C service stations.

  • FEATURES:

    • Fully automatic A/C service station for recovery, recycling and recharging of different types of refrigerants
    • Menu navigation is intuitive, professional, designed for an easy and rapid work with the machine
    • 7’’ color touchscreen
    • WI-FI connectivity
    • The unit can handle the hermetic oil and dye cartridges, as well as the hermetic and refi llable containers
    • The result is easy serviceability: less than 30” to open the revolving control panel and less than 2 minutes to remove both plastic covers and access all the internal components
    • QTECH IV grants excellent maneuverability as a result of the considerable axial distance between the two wheels
    • User-friendly features: pressure gauges and touch screen are perfectly inclined for excellent ergonomics
  • TECHNICAL DATA:

    Type of refrigerant: HFO1234yf or R134a
    Voltage: 220-240V  50/60 Hz
    Vacuum pump: 100 l/min, vacuum  level 0,1 mbar
    Sealed compressor: 1/3 HP
    Recovery speed: 300 g/min  in liquid phase
    Scale resolution: 10 gr
    Oil scale resolution: 5 gr
    Working temperature range: 11/49 °C
    Filter system: 1 filter for humidity
    Refrigerant tank: 12 liters refillable
    Hoses: 3 meters
    Automatic service valves: Standard
    Display: 7’’ color touchscreen
    Connectivity WI-FI: Standard
    Hybrid function / electrically driven compressors: Standard
    Pressure test forming gas / nitrogen: Standard
    Gas identifier / Gas Analyser: Option, Analyser
    Flushing kit: Option
    Status light: Standard
    Bottle heater: Standard
    Thermal printer: Standard
    A/C diagnosis: Standard (R134a)
    Hermetic and refillable containers for oil and dye: Standard 2 + 1
    Hermetic disposable containers for oil and dye: Standard 2 + 1
    Automatic air purge: Standard
    Dimension / weight: cm 67 x 68 x 108, 77 kg
    Dimension / weight with packaging: cm 71 x 74 x 125, 95 kg
